12V 280Ah LiFePO4 Battery Low-Temp 4000+ Deep Cycle 200A BMS For RV

Power Queen 12V 280Ah LiFePO4 Battery, Low-Temp Protection Lithium Battery, 200A BMS, 3584Wh Energy, 4000+ Deep Cycles for Cabin, Marine, RV ,Solar Power System, UPS

Single-Battery Supremacy: Replace 3x100Ah LiFePO4

A single 12V 280Ah LiFePO4 battery outperforms 3x12V 100Ah LiFePO4 setups with space savings, weight reduction and fewer connections. Eliminate the hassle of parallel wiring and voltage balancing while achieving extended runtime through consistent stability. Ideal for installations where space optimization and simplified maintenance are critical.

Massive 3584Wh Capacity for Versatile Scenarios

Designed for high power demands, this 280Ah LiFePO4 battery easily integrates with solar panels and inverters, delivering 3584Wh to energize RV expeditions, marine systems, off-grid homes and 12V all-electric truck APU systems, providing parking cooling and power, reducing engine run times, saving energy and reducing emissions.

Advanced BMS with 20+ Intelligent Safeguards

Optimized 200A BMS integrates 20+ safeguards - including low temperature cutoff, 30-second overload protection auto-recovery and overheat protection, etc. - to ensure stable operation and extend service life. Designed for extreme demands, it delivers 1000A@1s surge current to effortlessly handle power spikes for high wattage devices.

Marine Grade Durability, Ultra-Long Runtime

IP65-rated, salt-spray resistant battery for superior performance in harsh and extreme environments. Provides stable power for 12V trolling motors and on-board electronics. Large capacity ensures uninterrupted operation of leisure boating equipment such as refrigerators and air conditioners during extended trips, allowing for days at sea.

Max. 57kWh Flexible Expansion Home Energy

Unleash unlimited energy independence with our 12V 280Ah LiFePO4 battery system. It supports 16 unit configurations (4P4S) to achieve 51.2V 1120Ah capacity - delivering 57.344kWh of clean energy storage to fully meet your family's energy needs. We ensure that every battery passes rigorous performance and safety testing before it leaves the factory.

Spec.

Nominal Voltage: 12.8V

Rated Capacity: 280Ah

Cycle Life: 4000-15000 Cycles

Battery Energy: 3584Wh

BMS:200A

Max. Continuous Output Power：2560W

Max. Continuous Charge Current：200A

Max. Continuous Discharge Current：200A

Peak Discharge Current 1 Second：1000A

Charge Method：CC/CV

Charge Voltage：14.4V ± 0.2V

Recommend Charge Current：56A (0.2C)

Charge Temperature：32℉ to 122℉

Discharge Temperature：-4℉ to 140℉

Storage Temperature：14℉ to 122℉

Max. Expansion (Parallel & Series)：4P4S

Terminals：M8 bolts

Dimensions: L20.55*W9.45*H8.58inch

Weight: 59.2lbs

Material：ABS

Protection Class：IP65

Certifications：UL1973Test, FCC, CE, RoHS, UN38.3

Application :Solar, RV, Camper, Marine,Trolling motor,Off-grid

Feature: Low-temp Cut Off Protection

Packege Included:

12V 280Ah LiFePO4 Battery Pack *1

Product Manual *1

Please be noted: battery charger is not included.

FAQ

Q: Can I pair a Bluetooth Module for this battery to monitor the battery status on the phone?

A:No. This battery is not compatible with the Bluetooth module. You can use a 500A Battery Monitor With Shunt to keep track of battery status.

Q: Can I charge Power Queen LiFePO4 lithium batteries in cold weather (under freezing temperatures)?

A:LiFePO4 batteries can be safely charged within the temperature range of 32°F to 122°F (0°C to 50°C). The Power Queen 12V 280Ah LiFePO4 batteries feature low-temperature charging protection, which automatically halts charging when the cell temperature drops below 32°F, thereby preventing damage to the battery cells during charging in freezing conditions.

Q: How to charge Power Queen 12V 280Ah lithium batteries?
A:1. Using Solar Panels

The Power Queen 12V 280Ah battery can be fully charged by in one day (with effective sunshine 4.5hrs/day) by 1200W solar panels. It may take more than one day to fully charge the battery by ≥1200W solar panels since the duration and intensity of light would be a great factor for their charging efficiency.

2. Generator/Alternator

If the alternator or generator supports DC output, a DC-to-DC charger is needed to connect the battery to the generator; if your alternator or generator supports AC output, please add a suitable battery charger to connect the battery and the generator according to our recommendations. The Recommended Charging Voltage: 14.2V - 14.6V. The Recommended Charging Current: ① 56A (0.2C): the battery will be fully charged in around 5 hrs to 100% capacity; ② 140A (0.5C): the battery will be fully charged in around 2 hrs to around 97% capacity.

3. LiFePO4 Smart Chargers

To charge 12V battery, it is recommended to use 14.6V battery charger. The Recommended Charging Voltage: 14.2V - 14.6V. The Recommended Charging Current: ① 56A (0.2C): the battery will be fully charged in around 5 hrs to 100% capacity; ② 140A (0.5C): the battery will be fully charged in around 2 hrs to around 97% capacity.Related reading: Can I Charge a Lifepo4 Battery With a Lead Acid Charger?

It would take around 14h to charge when using 12V 20A lithium battery charger and around 7h to charge when using 12V 40A lithium battery charger.
